Chord Company C-View HDMI Cable

C-Series C-View HDMI Cable, by The Chord Company

Chord Company C-View HDMI cable is a cost-effective, high-performance display connection featuring heavily-shielded copper conductors. C-View HDMI benefits from a 48 GBps bandwidth with a resolution of 8k at 60 Hz or 4k at 120 Hz. It supports Dynamic HDR, HDCP2.3, eARC, 3D and all HDMI audio formats.

The HDMI performance standard is one of the fastest-moving in our industry. HDMI (High Definition Multimedia Interface) cables carry high-frequency signals alongside a 5-volt DC electric supply. These complex multi-purpose interconnects tend to be longer than most other cables in a system, with the possible exception of speaker cables.

Today’s high-technology house contains many devices producing high-frequency (HF) noise. Cables often act as aerials picking up this noise. Unfortunately, the longer the cable the better aerial it becomes. These unwanted high-frequency signals can penetrate unprotected cables and end up on the signal earth. To preserve these delicate signals, all Chord Company HDMI cables feature high-efficiency HF screening to minimise the noise pick-up.

Lengths

Chord C-Series C-View HDMI is available in the following length options:

• 0.75 Metre
• 1.00 Metre
• 1.50 Metre
• 2.00 Metre
• 3.00 Metre

Specifications

• Bandwidth: UHS 48 GBps+
• Resolution: 8K / 60 Hz, 4K / 120 Hz
• Dynamic Range: Dynamic HDR
• Operating Distance: Up to 3 m
• Primary Conductors: 28AWG Copper
• Insulation: Foam-PE
• Shielding: Twin AL Foil
• Cable Jacket: PVC
• HDMI Connector Shell: Gold-Plated Copper
• HDMI Connector Pins: 19-pin Gold-Plated Copper
• Termination: Hand Soldering
• HDMI Connector Backshell: PVC
• Cable Diameter: 7 mm

More Information

• Chord Company C-View HDMI Interconnect Cable
