Ferrum Audio HYPSOS Hybrid Power Supply Unit

HYPSOS by Ferrum Audio defines a brand new category of a hifi products. It is not a simple power supply but an audio component of its own – an equally (or even more) important part of a setup as any other.

HYPSOS offers a selection of unique features and even accounts for future software improvements – the device is software controlled with as few hardware dependent elements as possible.

Hybrid Power System - Linear/switching hybrid design to get the advantages from both techniques - low ripple and noise as well as fast transient response and high efficiency.

HYPSOS gives you the possibility to fine tune the output voltage for the best sound. The voltage level can be safely adjusted on-the-fly to allow easy comparison testing.

Compatibility with Apple TV remote, Trigger in/out connector; possibility to automate power-up of the devices with standby mode even without dedicated trigger connection.

Using pre-configured settings from the list of supported devices or setting custom parameters manually. Wide continuous output voltage range of 5 - 30 V with up to 6 A of current delivered to the load. HYPSOS is as universal a device as it gets.

4T Sensing Design (4TSD) ensures the exact voltage level precisely at the point of the powered device DC input terminal - special cable design and feedback to ensure flat voltage at every moment. This technique eliminates the harmful effects of the cable's resistance effectively improving transient response.

Extremely safe to use! Automatic Transformer Voltage Adjust (ATVA), Electronic Output Voltage Polarity Switch and over-voltage, current limit and short protection.

Features

• HYPSOS linear / switching hybrid power system.
• Allows fine-tuning of output voltage to perfectly tailor performance.
• Compatible with a HUGE variety of audio components - see the list.
• Input 110 - 240V AC
• Output 5 - 30V DC
• 6 A / 80 W

Specifications

• Power Input: 110-120, 220-240 V AC 50-60 Hz (EU/US Version) / 90 – 110 V AC 50-60 Hz (JP Version) / IEC C14 power inlet, a fuse holder with power on/off switch plus two-stage EMI filter for low impedance load with better noise attenuation in low frequency applications.
• Mains Cable: US / EU / UK
• DC OUT Cable: 5 x 2.5 mm DC plug / 5 x 2.1 mm DC plug / Custom cables made to order at additional cost.
• Output Voltage Range: 5 - 30 V
• Max Continuous Output Current (for V Out below 13.3 V ): 6 A
• Max Continuous Output Current (for V Out higher than 13.3 V): 80 W / DC Out V
• Maximum Impulse Current: 9 A
• Maximum Impulse Power: DC V Out 9 A (27 0W for 30 V)
• Max Continuous Output Power (for V Out below 13.3 V): 6 A
• Max Continuous Output Power (for V Out higher than 13.3 V): 80 W
• Dimensions (without knob, feet and connectors) (W x D x H): 217.5 x 206.5 x 50.0 mm
• Net Weight: 2.89 kg
• Primary Winding Fuse: IEC 5 x 20 mm, 250 V, 3.15 A, slow-blow (Japan) / 250 V, 2 A, slow-blow (EU/US)
• Secondary Winding Fuse: Littefuse 154004 T, 4 A
• Power Consumption: 230 V AC, 50 Hz @ 12 V DC out: Idle 6 VA @ 15 W load – 30.7 VA @ 60 W load – 98 VA @ 80 W load – 133.9 VA

Included

• 1 x HYPSOS Hybrid PSU.
• 1 x Mains Power Cable.
• 1 x DC Power Cable.
• 1 x Documentation.
