ISOL-8 IsoLink Ultra Mains Cable

IsoLink Ultra Mains Cable

The all new IsoLink Ultra power cables are the perfect solution to connecting your system to its vital power source.

They are the perfect complement to ISOL-8 power conditioners and class leading performers for any audio application in their own right.

The IsoLink Ultra takes a step further to place itself firmly in audiophile territory. The high purity copper conductors have been chosen by blind audition. The strand diameter and quantity chosen to be the optimum configuration for sound quality. Great care has been taken with the physical construction to preserve power transmission integrity.

Cables are made by a process of laying up the individual mechanical and electrical components with the outer jacket. The forms of these components are each circular in cross section and leave small voids between the components in the finished cable.

The high peak current pulses the cable has to deliver under typical operating conditions causes the conductors to move relative to one another under magnetostriction. This small dynamic instability in conductor geometry raises the cable noise floor, modulated by the current waveform and degrades performance.

The IsoLink Ultra undergoes a special process during manufacture to fill these small voids with an elastomer to maximise mechanical integrity and minimise this effect.

A carbon loaded polymer screen provides 100% cross sectional coverage to shield the conductions against electromagnetic interference. A flexible synthetic rubber jacket provides the final layer ensuring total mechanical stability with very low loss electrical characteristics.

After careful audition we have selected the audiophile standard Rhodium plated Cardas, Schurter and Neutrik connectors to complete the IsoLink Ultra's specification.

Stocked versions are available in 1.5M or 2.0M lengths, other lengths and terminations are available to special order with fast turnaround:

• Cable Termination
  • IsoLink Ultra UK: High quality 13A UK Plug + Schurter IEC connector.
  • IsoLink Ultra EU: Rhodium plated Cardas Plug + Schurter IEC connector.
  • IsoLink Ultra US: Rhodium plated Cardas Plug + Schurter IEC connector.
  • IsoLink Ultra UK Powercon: High quality 13A UK Plug + Neutrik latching 20 Amp professional connector.
  • IsoLink Ultra EU Powercon: Rhodium plated Cardas Plug + Neutrik latching 20 Amp professional connector.
  • IsoLink Ultra US Powercon: Rhodium plated Cardas Plug + Neutrik latching 20 Amp professional connector.
• Diameter: 12mm O/D
• Product weight: 0.4Kg (1.5M EU)
• Shipping weight: 1Kg
• Mains voltage: 100 - 260VAC
• Cable rating: 20 Amps
• Maximum current: UK versions fused at 10A (2300VA)
