Stax SRM-D50 Desktop Energiser / DAC

The Stax SRM-D50 drives STAX ‘s electrostatic earspeaker in an ideal form.

With the installation of a high-performance DAC, the SRM-D50 supports various audio sources such as Digital Audio Players and computer audio through USB / Optical and Coaxial connections as well as traditional analogue RCA.

Features

• Supports various audio sources such as USB / optical / coaxial digital input, RCA analog input etc.
• ESS DAC chip supports files with audio signal maximum DSD 5.6 MHz, PCM 384 KHz.
• Adopt R core power transformer with less leakage flux.
• Displays the strength of input signal with VU meter.
• Adopted 4 mm thick non-magnetic aluminum cover.

Specifications

• Frequency Response：DC 40 kHz (0 / -3 dB)
• Rated Input Level：130 mV RMS
• Max Input Level：30 V RCA, at minimum volume
• Max Output Voltage：400 V RMS (1130 Vp-p)
• Gain：59 dB
• Harmonic Distortion：0.025 % or less / 1 kHz - 10 kHz / When used with SR-L series
• Input Impedance：20 kΩ (RCA)
• Bias Voltage：DC 580 V
• Mains Woltage：AC 100 - 240 V ,50 / 60 Hz (depending on country voltage)
• Power Consumption：35 W
• Operating Temp: 0 - 35 C (less than 90 % humidity, non-condensing)
• Dimension (W x H x D)：192 x 67 x 268 mm
• Weight：4.5 kg
• Digital Input：USB Type-B x 1, TOSLINK x 1, Coaxial x 1
• Analog Input：RCA x 1

More Information

• SRM-D50 Energiser, by STAX Audio
