Vertere Acoustics Pulse-XS Speaker Cable (Factory Terminated)

Pulse-XS Speaker Cable, by Vertere Acoustics.

Giving superb performance in its own right, Pulse-XS Speaker Cable is second only to Pulse-XS Reference and of course the highest Pulse-HB series of cables. Terminated with Vertere Special connectors.

Pulse-XS is similar to the Reference version, utilising the same unique Pulse-XS Cable, but terminated in Vertere Special high performance 4mm Banana or Spade connectors. Pulse-XS signal conductor is also fully shielded to provide highest performance at this price point.

Optional Features

• Integral Terminal Jumper (ITJ)
  Where the speaker has more than one pair of input terminals, ITJs would allow terminal connections without the necessity of using compromised binding post links.
• Speaker Terminal Link (STL)
  Additionally, a set of speaker terminal links can ben supplied using the same materials as used by the Pulse-HB speaker cable. These may be used as an alternative to ITJ's, or in addition to, for some tri-wireable loudspeakers.
• Bridged-Balanced Mode
  Pulse-XS Reference is terminated in Bridged Balanced mode, suitable for all amplifier speaker outputs. Bridged outputs are effectively two power amps, where ‘Black’ terminals are joined together and unused – a floating ground system. The two ‘Red’ terminals then become the new Red and Black terminals. Here one of the amps is inverted which results in an overall output twice the single amp output – thus twice the power. In this bridged balanced mode both the red and the black terminals are AC audio signal and require exactly the same type of signal conductor for connection to the speakers. Pulse-XS Reference terminated Bridged Balanced has two signal conductors identical and shielded for optimum performance.
• Single-Ended Mode
  Generally a power amplifier’s ‘Black’ output terminal is in fact connected to the amplifier signal ground and carries no signal. This is the DC Zero reference for the ‘Red’ terminal which carries the entire audio AC signal. For this reason the Pulse-XS can be terminated with its ‘Black’ conductor different to the ‘Red’ to suit DC zero reference better, which could marginally enhance performance. The ‘Red’ signal conductor remains shielded and the shield connection is managed by the unique switchable Shield Management Block.

Specifications

• Type: Stereo Loudspeaker Cable
• Termination & Length: 4mm Banana, Spade, 2.00m (Additional lengths in 0.5m steps)
• Cable Type: x11 & x1 Conductors, Pulse Multi Type
• Conductor: High Purity Copper
• Plating: Silver, Tin
• Insulation: PTFE, PVC
• Shield: Main Braid for signal
• Connector: Vertere x3 thickness gold-plated contacts
• Size: 5.6 x 10.5 mm
